RRD fan extension module-OKY3916 – OKYSTAR

OKY3916

RRD fan extension module

Product Description

1) 20V MAX Supply Voltage

2) connect the RRD-FAN-

EXTENDER to 12V,5V,.. flexible

Output voltage

2A MAX currence

Maximum 20 V
2 (PWM) control channel (D6/D11)
Each channel 0.5A biggest (enough for A real big fan)
Flexible output voltage (you can connect the RRD FAN extended to support what you need to the output voltage of 12 v, 5 v,…).
Easy to install (plug and play)
Marlin firmware (select “# define the mainboard easily adapapt other firmware (such as sprint: just change the # define FAN_PIN6 in pins. h” “)

Call on Whatsapp

Share This Product

Product Details

Product Description

Description:

If you build or upgrade your printer and a dual (2 machine) including all the output ports (D8, D9, D10) on the heated bed, it will be used.
In this case, there is no option to connect the firmware control fan to the inclined plate directly.
However, in sprint /Marlin firmware, there is an option already (Marlin: plate = 34), and the slope of the fan is output D4. But the plan needs a buffer / drive job.
