Description:
- JDY-25M Super Bluetooth function supports master-slave transparent transmission,BLEprobe, detection.
- MESH networking, and the maximum number of MESH networking supports 65280 device networking, adopts multi-wireless anti-collision technology, and the networking communication speed supports 50mS transmission 12-byte data.
- Asingle module supports router nodes and terminal nodes, router nodes support data relay (low power consumption is not supported), terminal nodes support low power consumption (automatic sleep after key-press wake-up sending data),
- JDY-25M networking Generally, you only need to configure the networking NETID and short-circuit address, the module will be automatic, when the networking module communicates with the APP.
- It is equivalent to transparent transmission, which greatly facilitates the user to develop APP compatible with the old product APP.
Specification:
1.Working voltage: 1.9-3.6V
2.Working temperature: -40-85°C
3.Maximum transmit power: +4dbm
4.Communication distance: 80m
5.Antenna: PCB onboard antenna
6.Antenna gain: -3dbi
7.Receiving sensitivity: -96dbm
8.Communication interface: UART
