ESP-02 ESP8266 Nodemcu IOT Remote Serial Port Wifi Transceiver Wireless Sensor Module–OKY3366-1

Product Model: OKY3366-1

ESP-02 ESP8266 Nodemcu IOT Remote Serial Port Wifi Transceiver Wireless Sensor Module

Product Description

Function:wireless,wifi transportation and receiving
Available:DIY project,student,engineer,programmer
Type:ESP-02
Wireless standards: 802.11 b / g / n
Frequency range: 2.4GHz-2.5GHz (2400M-2483.5M)
Data interface: UART / HSPI / I2C / I2S / Ir Remote Contorl GPIO / PWM
Operating voltage: 3.0 ~ 3.6V (recommendation 3.3V)

Send Inquiry

Chat Online

Call on Whatsapp

Share This Product

Product Details

Product Description

1. Support 802.11 B/G/N
2. Communication range up to 100 yards depending on environment.
3. Standard 3.3VDC operation with 5V compatible I/O.
4. Standard 3 wire (TXD/RXD/GND) serial communication (idle high) at 115200/8/N/1.
5. Standard 0.1″ (2.54mm) half through hole.
6. Upgradeable firmware.
7. Three mode of operations: Client/Access Point/Both Client and Access Point.
8. Support all major security schemes: OPEN/WEP/WPA_PSK/WPA2_PSK/WPA_WPA2_PSK.
9. Support both TCP and UDP communication.
10. Working as TCP/UPD server supports up to five (5) connections.
11. Working as station can connect up to 5 TCP/UPD servers. The ESP-02 can connect to all standard non-SSL
websites in the world.
12. Simple AT commands for all operations.
13. Connection based data reception or transparent data reception.
14. Programmable client connection inactivity timeout.
15. Automatic domain name address resolution for public domain name but not the local name within the local
area network (router).
16. Detailed English user manual in PDF format and will be upon purchasing via email.
