Product Model:OKN515-16

DC 9V To 60V PWM DC Motor Speed Controller Control Motor

Product Description

1.Input Voltage Range: DC 9V To 60V output voltage

2.Linear Load Output Current: 0A To 20A

3.Continuous Power: 1200W

4.Speed Control Mode: Potentiometer (linear)

5.Speed Range: 0 To 100%

6.Input Current: Requires more current than the motor

7.Continuous Current: Within 18A

8.The input voltage should be equal to the rated voltage of the motor.

9.Control frequency: 25KHz clockwise / counterclockwise rotation;

10.DC brush size: 92*52*36MM

11.Potentiometer Mounting Hole Diameter: 7MM

12.Wiring connection: thick red line: power +, thick black line: power -, blue and green motor is not positive or negative
