100% Brand New & High Quality

• 1.The length is 45* wide 24* high 11mm (including potentiometer)
  2.Input mode: IN+ input positive, IN- input negative
  3.Output mode: OUT+ output positive, OUT-output negative
  4.The input voltage: 4.5-60V (Note: higher than 50v can not work for a long time)
  5.Adjustment mode: firstly connect the input power supply (between 5-60V) and then use the multimeter to monitor the output voltage and adjust the potentiometer (generally turn the booster clockwise, reverse the buck)
  6.Output voltage: (3-35V) continuously adjustable (no-load debugging is recommended).
  7.Pressure difference: at least 1.5V
  8.Output current: rated current 2A, no more than 3A
  9.Output power: no more than 15W
  10.Conversion efficiency: 92% or less (the higher the output voltage, the higher the efficiency),Static power consumption is only about 6mA
  11.Connection mode: welding, after add pin can be directly welded on the PCB
  12.Working temperature: industrial grade (- 40 to + 85 )
  13.Load regulation: ± 1%
  14.Voltage regulation: ± 0.5%
  15.Short circuit protection: current limiting, overheating protection
